Provide isolated power distribution for field transmitters while enabling the conversion of various signals such as voltage, current, and mV. The input terminal interface is compatible with current sources, two-wire, and three-wire transmitters. Internally, it employs efficient magnetoelectric isolation technology, ensuring isolation between input, output, and power supply. It features high precision, high linearity, low-temperature drift, and other advantages.

Technical Parameters:

Input signal: 4-20mA; 0-20mA; 0-5V; 0-10V; others
Input impedance: 50Ω
Output signal: 4-20mA; 0-20mA; 0-5V; 0-10V; others
Output load resistance:
RL＜500Ω (when the output is a current signal)
RL＞10KΩ (when the output is a voltage signal)
Power source: DC24V, ±10%
Current consumption:
＜50mA (1 IN 1 OUT,DC24V,output 20mA)
＜70mA (1 IN 2 OUT,DC24V,output 20mA)
＜100mA (2 IN 2 OUT,DC24V,output 20mA)Accuracy: 0.1% F.S.
Temperature drift: 0.005% F.S./°C (-20°C～+55°C)
Response time: 10mS (0-90%) (TYP)
Insulation strength:
1500VAC/1min (between input,output,power)
Insulation resistance: 100MΩ(between input,output,power)
Operating temperature range: -20 ~ +55 ° C
Applicable field devices: 2 wires, 3 wires, current source
